Product Description
Step into the future of electric vehicle (EV) charging with Ruihua's comprehensive range of EV Charger ODM & OEM services. As a leading provider of customized charging solutions, we offer unparalleled expertise in tailoring EV chargers to meet the unique needs and specifications of our clients worldwide.
Multi-standard: CCS1, CCS2
Network or standalone operation
Support smart charging and load balancing
Multiple protection to ensure users' safety
OCPP 1.6 JSON/ OCPP 2.0.1
( Comply with latest OCPP protocol as Ruihua is the member of OCA )
|
Input Connection |
3-Phase : 3P+N+PE |
|
Input Voltage |
400V/AC ±15% |
|
Frequency |
50Hz or 60Hz |
|
THDi |
≤5% |
|
Power Factor |
≥0.98 |
|
Output Voltage |
150Vdc - 1000Vdc |
|
Max. Output Current |
200A（ 250A optional） |
|
Rated Power |
120kW - 240kW |
|
User Interface & Control |
|
|
LCD Display |
7" Color Touch Screen |
|
LED Indicator |
Green/Yellow/Red |
|
Charging Interface |
CCS2 Plug( CCS1 Plug / CHAdeMO optional ) |
|
Number of Charging Interface |
2 |
|
Energy Measuring |
Embedded meter, with 1% accuracy |
|
Communication |
|
|
Backend |
Ethernet( Bluetooth / Wi-Fi/ 4G Optional ) |
|
Charging Protocol |
ISO 15118 , DIN 70121 |
|
Backend Protocol |
OCPP 1.6 JSON ( OCPP2.0.1 ) |
|
Protection |
|
|
Residual Current Device |
Yes |
|
Internal Fuse |
Yes |
|
Electrical Protection |
Over/Under Voltage Protection,Over Current Protection, Short Circuit Protec- |
|
Environmental |
|
|
Operating Temperature |
-30℃—+55℃ |
|
Storage Temperature |
-40℃—+75℃ |
|
Operating Humidity |
Max. 90% RH, Non-Condensing |
|
Operating Altitude |
≤ 2000m |
|
IP, IK Level |
IP65, IK10 |
|
Cooling Method |
Independent air duct |
|
Mechanical |
|
|
Product Dimension |
1780*800*950 mm (H*W*D) |
|
Charging Cable Length |
5m |
|
Weight |
60kw: 390kg; 120kw: 420kg; |
|
Mounting |
Free Standing |
|
Certifications |
|
|
Certifificate |
IEC62196-1, IEC62196-3, IEC 61851-1, IEC61851-23, IEC61851-24 |
|
Safety |
CE |
|
EMC |
Class B |
• ODM (Original Design Manufacturing): Collaborate with our team of experts to develop and manufacture EV chargers that align perfectly with your brand identity and market positioning. Our ODM services allow you to offer a distinctive product line that stands out in the competitive EV charging landscape.
• OEM (Original Equipment Manufacturing): Trust Ruihua to produce high-quality EV chargers under your brand name. Our OEM services ensure that your customers receive reliable and efficient charging solutions that uphold the reputation of your brand.
After receiving customer orders, we decompose customer needs based on existing products and technology platforms, and focus on standardized product sales, supplemented by partial customization, to form corresponding product design solutions. Our products adopt a modular design, and the power modules can operate independently, or multiple modules can be assembled into a complete machine. In the production process, we first produces modules and then complete machines, which improves production efficiency while meeting the customized needs of customers; according to customer needs, it can deliver both complete machine products and module products to customers.
• Customization Excellence: Ruihua specializes in crafting custom EV chargers designed to meet your unique specifications. Whether you require specific features, branding elements, or technical requirements, our team ensures that your vision is brought to life.
• Engineering Expertise: With a team of experienced engineers and designers, Ruihua excels in developing cutting-edge EV charging solutions. From hardware design to software integration, we leverage our technical expertise to deliver high-quality products that exceed industry standards.
• Flexible Manufacturing: Ruihua's state-of-the-art manufacturing facilities are equipped to handle projects of varying scales. Whether you need a small batch or large-scale production, our flexible manufacturing capabilities ensure timely delivery without compromising quality.
• Quality Assurance: Quality is at the forefront of everything we do. Ruihua adheres to rigorous quality control standards throughout the manufacturing process to ensure that every EV charger meets our stringent criteria for performance, reliability, and safety.
• Strategic Partnership: Partnering with Ruihua for your EV Charger ODM/OEM needs means gaining a strategic ally dedicated to your success. We work closely with our clients to understand their goals, offering guidance and support at every stage of the process.
• Global Reach: With a strong global presence, Ruihua is well-positioned to serve clients worldwide. Whether you operate locally or internationally, our team is committed to delivering exceptional ODM/OEM solutions tailored to your market needs.
Experience the difference with Ruihua's EV Charger ODM/OEM services. Contact us today to discuss how we can bring your vision of customized electric vehicle charging solutions to reality.
Whether you're an established player in the EV market or a newcomer looking to make a splash, Ruihua's EV Charger ODM & OEM services provide the perfect foundation for success. With our expertise, you can create a standout product line that delivers exceptional performance, engages customers, and drives your brand forward.
Partner with Ruihua today and experience the power of customized EV charging solutions – where innovation meets your unique vision, and sustainability meets opportunity.
